SOMAPULSe User Guide

  • PRODUCT SAFETY DISCLAIMER:

    This device (SomaPulse) is not a medical device. It contains a strong magnet. Do not use if you have a pacemaker, implanted cardioverter defibrillator (ICD), insulin pump, or other implanted electronic medical devices.

    Consult your healthcare provider before use if you have any medical conditions, are pregnant, or have metal implants. Keep away from electronic devices and credit cards. Not suitable for children of any age or pets.

    This device contains an integrated battery. Do not place in the washer or dryer, iron, throw, step on or cause direct impact to.

    Avoid direct skin contact and always use a fabric layer in between the device and your skin.

    Hyperlock fabric connectors contain sharp hook components and may leave marks in non woven fabrics such as leather.

    Do not place fingers in the Hyperlock hook zone.

The Basics

charge your somapulse with the included usb-c cable and adapter. It is fully charged when the battery indicator on the display shows solid green

ONCE FULLY CHARGED:

  • Detach the USB-C cable (device operates via battery only)

  • POWER UP YOUR SOMAPULSE DEVIce by pressing & Holding either button for 4 seconds

  • the device will enter standby as indicated by an s- symbol

Vibrating massager control panel with power settings and buttons on grey textured surface with green border.

S- Indicates Standby Mode

You can now select your desired heat/vibration mode. Press the buttons on the switch to cycle between modes.

To lock physical buttons and set timers, install the Spatium Systems app on your smartphone.

Waveform-like symbol in a circle
Hot springs icon, steam rising from water, line art.

Vibration: 1 / 2 / 3 / Off

Heat: Low / M / High / Off

  • The device takes around 4 minutes to fully heat up and release FIR heat.

  • The 3D Mesh Side Is Hotter :)

Connect SomaPulse in 4 ways:

Green mechanical device with multiple black knobs or switches on its surface, partial view, against a gray background.
Animated GIF of a spiral strip unfurling and rolling across a flat black surface with a green rectangular tab.
Rectangular wire mesh with yellow border on a white background

hyperlock

Dark gray jacket with open front and visible lining, displayed on a modern gray background.
black and yellow JBL portable speaker on textured gray background
Finger pressing a yellow button with black details on a textured surface
Prohibited symbol, red circle with white slash

Caution‎ ‎ ‎ ⛔

DO NOT PLACE FINGERS IN THIS ZONE ‎ ‎ ⛔‎

Caution‎ ‎ ‎ ⛔ DO NOT PLACE FINGERS IN THIS ZONE ‎ ‎ ⛔‎

Hyperlock is designed to connect SomaPulse to a range of woven fabrics. Hyperlock attaches to SomaPulse via velcro connection, and to objects via expandable hooks. The patented technology works best on thick, woven fabrics.

⛔ Do not place fingers in the black hook connection zone
⚠️ Hyperlock may leave marks on fabrics such as leather

  • 3-4 are recommended.

    If you find that SomaPulse is causing your jacket to flap, rotate SomaPulse upside down when connecting to your jacket.

    This will reduce / correct this effect.

  • 3-4 are recommended

  • 2 are recommended

step 1

Gently remove disclaimer film from hyperlock units

This will expose the black universal fabric connection zone.
Please keep your fingers away from this zone.

The other side of Hyperlock contains velcro hooks.
This side will attach to your SomaPulse device - please follow the steps below.

step 2

attach hyperlock onto the black velcro side of somapulse

Rotate clockwise and counterclockwise. Use downward force / pressure to ensure a good connection between velcro surfaces.

Before step 3, ensure the expandable hooks are fully retracted / hidden. This is indicated by the movable lever set towards the rightmost side, when the black connection zone is visible.

Recommended Hyperlock Placement

turtle shell template design with circular patterns
Blank shield design with black background and yellow polka dot border
Baby onesie with light gray and black with green trim design

step 3

position somapulse with hyperlocks onto your fabric

Make sure the Hyperlock black hook connection zone is facing towards your fabric.

Push down with equal pressure on each Hyperlock and rotate the lever clockwise.

This process will engage and connect the Hyperlock hooks onto your target fabric. It is important to place downward pressure on the Hyperlock when rotating the lever, to ensure all hooks lock onto your fabric.

Continue to maintain pressure until the lever is fully rotated.

Once fully rotated, inspect the connection to ensure Hyperlock is fully connected.

  • A note for jacket connections:

    If you find that SomaPulse is causing your jacket to bounce, rotate SomaPulse upside down when connecting to your jacket, so that the control switch is located near the top left of your jacket. This will bring the battery closer to the top of your jacket, reducing weight near the bottom and resolving the bounce effect.

  • Rotate each connected Hyperlock lever counter-clockwise to disengage from the fabric.

    Ensure that the lever is fully rotated on each Hyperlock before disconnecting and removing SomaPulse from your target fabric.

Close-up of a hand lifting a round section of a garment to reveal a mesh behind a padded layer with a yellow rim.
Hand lifting textured padded material with reflective surface and yellow edge, placed on grey fabric
close-up of fabric textures with a yellow buckle

Push Down & Rotate Lever

Push Down & Rotate Lever

Green check mark symbol

Body StraP

Loop animation of a green shape navigating through a spiral on a black background.
Person with protective back gear sitting on a cube, colorful background

step 1

align the 3 green velcro strips of the body strap with the upper half of your somapulse device

The upper half of SomaPulse contains the vibration motors. Aligning the upper half of SomaPulse with the elastic strap ensures the motors perform as intended.

step 2

wrap the strap around your body

Once the strap is positioned across your back, finalize attachment by connecting the green velcro hook patch to one of the preset white loop patches.

If the strap isn’t long enough, use the included leg strap as an extender.

Leg StraP

Rectangular wire mesh with yellow border on a white background

step 1

Attach the strap to the velcro side of Somapulse

Once the strap is connected to SomaPulse, wrap it around your leg.

SomaPulse can be connected to the leg with the velcro side facing outwards or inwards. The pad will deliver more heat with the 3D mesh facing towards your leg.

also functions as a body strap extender

also functions as a body strap extender

Magnet

step 1

Every somapulse comes with an internal and detachable magnet

Remove the detachable magnet from the top of the unit and place / hold it behind the back of your mesh chair. Position SomaPulse in front of the mesh chair, and it will lock on to the magnet.
